Unmatched Expertise in

Well Intervention Products & Services

Black Bear Pte Ltd stands as a premier well intervention specialist, offering a broad range of products and services designed to meet your unique project needs. Our offerings are comprehensive, tackling challenges from fishing, side-tracking, well abandonment, and thru-tubing, along with the design and fabrication of specialty tools like our high-speed jetting tool and non-explosive multi puncher.



Our dedicated teams bring together years of experience and industry know-how, ensuring that the tools we create not only meet industry standards but set them.

Our focus extends beyond simply offering services. As a leading well intervention specialist, we partner with you, bringing innovation, agility, and efficiency to your operations. At Black Bear, we don’t just deliver services; we shape successful well intervention outcomes.

Fishing,
Side-Track,
& Well Abandonment

View More >

THRU-TUBING

View More >

Our Equipment

Fishing

  • Overshots
  • Spears
  • Box/Tapered taps, LIB, String/Fishing/Ditch magnets
  • Junk/String/High Performance Bladed Junk Mill
  • Fishing Jars/Intensifier/Bumper Sub
  • Washover equipment
  • Packer retrieval system
  • *Custom tools for fishing

Side Track

  • Single trip hydraulic whipstock – Retrievable
  • Single trip mechanical whipstock – Retrievable
  • Single trip hydraulic packer type whipstock

Well Abandonment

  • Pilot mill
  • Section mill
  • 20” x 36” Multi string conductor cut and pull system

Thru-Tubing

  • Metal to Metal Motor
  • Coil tubing motor
  • Coil tubing bidirectional jar/intensifer
  • Flo-Release overshot/spear
  • Flo-Release GS Type pulling tool
  • Flo-Release heavy duty pulling tool
  • Motorhead Assembly, Hydraulic disconnect, Flapper valve
  • High power, high temp magnet
  • Fluted centraliser
  • Jetting nozzles
  • Rotary jet wash tool
  • Circulating sub

CASE STUDY

Cut & Pull 7” Full Length Liner

FISHING OPERATIONS:

At Black Bear Pte Ltd, we don’t just claim to be a leading well intervention specialist – we have a track record of success to back it up. One of our notable projects involved a complex operation to cut and pull a full-length 7″ liner.

During this project, we conducted fishing operations utilizing aggressive button inserts. Our highly skilled team successfully pilot milled 5ft of the 7″ casing hanger from 2,814ft to 2,819ft. Subsequently, we managed an additional 10ft of 7″ casing at a rate of penetration (ROP) of 5ft/hr.

What stood out in this operation was the minimal wear on the pilot mill OD blades, a testament to the precision and care with which we conduct our operations. The highlight of this project was retrieving the full length of the 7″ casing back to the surface, underscoring our commitment to effective, efficient, and successful outcomes.

At Black Bear Pte Ltd, we don’t just claim to be a leading well intervention specialist – we have a track record of success to back it up. One of our notable projects involved a complex operation to cut and pull a full-length 7″ liner.

During this project, we conducted fishing operations utilizing aggressive button inserts. Our highly skilled team successfully pilot milled 5ft of the 7″ casing hanger from 2,814ft to 2,819ft. Subsequently, we managed an additional 10ft of 7″ casing at a rate of penetration (ROP) of 5ft/hr.

What stood out in this operation was the minimal wear on the pilot mill OD blades, a testament to the precision and care with which we conduct our operations. The highlight of this project was retrieving the full length of the 7″ casing back to the surface, underscoring our commitment to effective, efficient, and successful outcomes.

At Black Bear, we strive to set benchmarks in well intervention. Our successful projects are more than just achievements; they are concrete examples of our professionalism, expertise, and commitment to delivering exceptional results.

At Black Bear, we strive to set benchmarks in well intervention. Our successful projects are more than just achievements; they are concrete examples of our professionalism, expertise, and commitment to delivering exceptional results.

Efficient Retrieval in Challenging Circumstances

During a critical phase, a Gamma Ray and downhole Sampler got lost in the hole accompanied by 1,654ft of braided wireline. The task was not only to address the significant length of the lost wireline but also to ensure the efficient and safe retrieval of the tools without compromising the integrity of the well.



Leveraging our advanced tools and proven expertise:

  1. We deployed a 9-7/8” Smooth OD Bladed Convex Mill, efficiently milling a total of 1,654ft of the braided wireline, reaching a depth of 4,281ft.
  2. To ensure no remnants were left behind, we chased the fish inside the 8-5/8” casing utilizing a 7-7/8” Smooth OD Convex Mill.
  3. As a final step, the 5-1/2” Scrubgrab and 5-7/8” Overshot were run into the hole, ensuring a successful retrieval of the fish back to the surface.
During a critical phase, a Gamma Ray and downhole Sampler got lost in the hole accompanied by 1,654ft of braided wireline. The task was not only to address the significant length of the lost wireline but also to ensure the efficient and safe retrieval of the tools without compromising the integrity of the well. Leveraging our advanced tools and proven expertise:
  1. We deployed a 9-7/8” Smooth OD Bladed Convex Mill, efficiently milling a total of 1,654ft of the braided wireline, reaching a depth of 4,281ft.
  2. To ensure no remnants were left behind, we chased the fish inside the 8-5/8” casing utilizing a 7-7/8” Smooth OD Convex Mill.
  3. As a final step, the 5-1/2” Scrubgrab and 5-7/8” Overshot were run into the hole, ensuring a successful retrieval of the fish back to the surface.
This operation highlighted Black Bear’s commitment to overcoming challenging scenarios, showcasing our technical proficiency and the efficacy of our tools, from aggressive convex mills to precise retrieval tools like Scrubgrab and Overshot. Choose Black Bear for results that speak for themselves.

This operation highlighted Black Bear’s commitment to overcoming challenging scenarios, showcasing our technical proficiency and the efficacy of our tools, from aggressive convex mills to precise retrieval tools like Scrubgrab and Overshot.

Choose Black Bear for results that speak for themselves.

Streamlining Operations with Single-Trip Acidizing and Cleanout

In their quest to achieve better operational efficiency, a client grappled with the challenge of cleaning out the 2-7/8” tubing and performing acidizing – both operations traditionally requiring separate trips. The conventional method was to deploy a 2-1/8” motor to clean out the 2-7/8” tubing, only to follow it up with another separate trip dedicated to acidizing. This dual-run approach inevitably prolonged rig time, adding to operational costs and inefficiencies.

Understanding the client’s need for a more streamlined operation, Black Bear proposed a transformative approach:

Utilize a 2-1/8” Metal-Metal Motor integrated with a flat bottom mill. This innovative setup was specifically tailored to concurrently clean out the 2-7/8” tubing and undertake acidizing in just one run. By condensing two traditionally separate operations into one, Black Bear directly addressed the client’s core objective.

In their quest to achieve better operational efficiency, a client grappled with the challenge of cleaning out the 2-7/8” tubing and performing acidizing – both operations traditionally requiring separate trips. The conventional method was to deploy a 2-1/8” motor to clean out the 2-7/8” tubing, only to follow it up with another separate trip dedicated to acidizing. This dual-run approach inevitably prolonged rig time, adding to operational costs and inefficiencies. Understanding the client’s need for a more streamlined operation, Black Bear proposed a transformative approach: Utilize a 2-1/8” Metal-Metal Motor integrated with a flat bottom mill. This innovative setup was specifically tailored to concurrently clean out the 2-7/8” tubing and undertake acidizing in just one run. By condensing two traditionally separate operations into one, Black Bear directly addressed the client’s core objective. The revised approach bore tangible results. Not only were the operational objectives successfully met, but the client also reaped the benefits of optimized rig time. This translated to significant time and cost savings, underlining Black Bear’s commitment to driving operational excellence and delivering value. Through keen understanding and innovative solutions, Black Bear continues to redefine operational strategies, ensuring clients receive the best in efficiency and effectiveness.

The revised approach bore tangible results. Not only were the operational objectives successfully met, but the client also reaped the benefits of optimized rig time. This translated to significant time and cost savings, underlining Black Bear’s commitment to driving operational excellence and delivering value.

Through keen understanding and innovative solutions, Black Bear continues to redefine operational strategies, ensuring clients receive the best in efficiency and effectiveness.

Revolutionizing Tubing Punch Operations with a Safer Alternative

Traditionally, the oil and gas industry relied on explosive perforating guns to punch holes in tubings. While effective, this method harbored inherent risks. The explosive nature of these perforating guns posed significant safety concerns. Moreover, there was a conspicuous absence of slick line tools in the market capable of performing this task.



Rising to the challenge, Black Bear introduced a game-changing tool:

The first of its kind, this innovative tool is capable of punching holes in tubing and is conveyed via slick line, filling a notable gap in the market.



By doing away with the need for traditional explosive perforating guns, it significantly amplifies the safety profile of tubing punch operations.



Additionally, when compared to e-line tubing punchers, Black Bear’s solution is more cost-effective, making it an economical choice without compromising on performance.

Traditionally, the oil and gas industry relied on explosive perforating guns to punch holes in tubings. While effective, this method harbored inherent risks. The explosive nature of these perforating guns posed significant safety concerns. Moreover, there was a conspicuous absence of slick line tools in the market capable of performing this task.



Rising to the challenge, Black Bear introduced a game-changing tool:

The first of its kind, this innovative tool is capable of punching holes in tubing and is conveyed via slick line, filling a notable gap in the market.



By doing away with the need for traditional explosive perforating guns, it significantly amplifies the safety profile of tubing punch operations.



Additionally, when compared to e-line tubing punchers, Black Bear’s solution is more cost-effective, making it an economical choice without compromising on performance.

The introduction of Black Bear’s groundbreaking tool not only filled a niche in the market but also redefined operational safety standards. Clients could now punch holes in tubings without the associated risks of using explosive devices. Coupled with the cost savings against traditional e-line tubing punchers, the tool became a testament to Black Bear’s dedication to innovation, safety, and value-driven solutions.

Black Bear continues its legacy of transforming traditional operations with safer, more efficient alternatives, cementing its position as a forward-thinking leader in the industry.

The introduction of Black Bear’s groundbreaking tool not only filled a niche in the market but also redefined operational safety standards. Clients could now punch holes in tubings without the associated risks of using explosive devices. Coupled with the cost savings against traditional e-line tubing punchers, the tool became a testament to Black Bear’s dedication to innovation, safety, and value-driven solutions.

Black Bear continues its legacy of transforming traditional operations with safer, more efficient alternatives, cementing its position as a forward-thinking leader in the industry.
